Hexohm V2.1 Pot Chart

Discussion in 'Charts' started by TheKidnappedOne, Mar 24, 2017.

  1. TheKidnappedOne

    TheKidnappedOne New Member

    Blog Posts:
    0
    Joined:
    Mar 10, 2017
    Messages:
    27
    Yeah sure the 2.1 might be last years news, but for those out there that still love your 2.1 or maybe you bought a used one, I spent a night working out a small chart that fits rather nicely inside the battery compartment, that breaks down the voltage at each percentage of the potentiometer and then broke down that the Amperage and Wattage would be at different Resistance settings.

    [​IMG]

    This is available to anyone that wants it, and hell if you want I have the Indesign files still and can give that out for anyone hat wishes to make adjustments to fit their needs.

    skt239 likes this.
  2. skt239

    skt239 VU Donator Platinum Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    Sep 16, 2015
    Messages:
    5,429
    I don't have one but thanks anyways!

  3. TheKidnappedOne

    TheKidnappedOne New Member

    Blog Posts:
    0
    Joined:
    Mar 10, 2017
    Messages:
    27
    No problem, its there for anyone that can make use of it. Hell leave out the percentages and you still get a good chart for say voltage controlled devices.
