Hi Folks
With top airflow RTA’s appearing round every corner and under every rock this year; it’s going to take something special at the mid-year mark for me to sit up and take note, in fact if I’m being completely honest I’m a little washed out at the thought of reviewing any more “samey” top airflow tanks, at least that is without keeping my finger firmly off the “yawn” re-run review button.
However Augvape were brave…praise both the vape and coil building gods; Mike gave us Snorkels baby! so In obligatory tradition Augvape kindly sent me the Intake RTA for the once over. As always I don’t like to make recommendations in my reviews, instead I’ll present you with my findings to help bolster your research should you be interested in the product.
Specification Overview & What’s in the box
Available Colours: Black, Stainless, Blue, Gun Metal
Impressions, Build Quality & Assembly
Let’s start with the low profile stock drip tip, it’s unusual to say the least, it’ll be one of those you’ll either grow to like (unless you already happen to enjoy a tail pipe style of vaping) or like me it’ll remind you of one of those blow up pillow rings to relieve pile/coccyx pain. To be fair as with all of the releases Mikes involved with; he always makes sure there’s options included to cater for as many people as possible, so you have a taller, more normal 810 included with a slightly larger tapered bore (see my measurements). There’s also a 510 adaptor which is what I chose to use since the chimney bore is a 510 diameter anyway (at 5.9mm).
I appreciate why Mike went for the low profile tip because the whole top portion of the RTA is a little on the tall side, and running a tall drip tip would have enhanced that aspect further. To me it’s not the prettiest tank out there but it’s certainly functional. The top cap is a quarter twist bayonet style, and due to its height you have plenty to grab onto making refilling an absolute doddle; even for those who have weakness in their fingers. Not only that but the seal underneath has some decent flex to it; meaning it doesn’t squeeze juice out of the seams easily after fastening which I’ve seen on other top airflow atomisers.
The only area of critique around the top section is the O-ring holding the airflow ring in place. I think it would have been better to locate it at the top rather than bottom since juice has a tendency to get underneath it after removing/securing the top cap repeatedly.
Fit and finish is generally good throughout, as is the paintwork. On this matte black version you cannot see any of the gaudy branding we have become accustomed to from Mike in the past, even the engraved “Intake” writing on the chamber is difficult to see which I personally prefer. The only two areas of critique were the edges of my deck could have been sanded better during the final manufacturing stage; also the O-Ring around the base pops out a little too easily when cleaning so keep an eye you don’t lose it.
The tank comes with two types of glass, the 4.2ml bubble for those who like a little more capacity, and the 3ml straight for those who prefer the slender profile with their set ups. I managed to knock my mod over a few times since taking notes for this review and thankfully the bubble glass was thick enough to take it. This is an area to take into consideration when using slimmer mods though and I was probably lucky to get away with it, so note to self: use a band with the bubble as it extends out to 27mm diameter at its widest point, whereas the base is 24mm.
Some parts of the Intake design aren’t dissimilar to other top airflow released this year;
Really that’s where the similarities end though, considering how it looks on the outside they have managed to fit a lot inside that chamber housing, it’s a little like Dr. Who’s tardis: you get a decent build space, two snorkel tubes, 2 decent sized wicking wells and a wide bottom airflow all crammed into a 19mm diameter area, I’m pretty impressed. I fed back to Augvape (prior to this review) that I’d like to have seen those tubes sport slightly wider diameters just to increase the airflow range slightly, but to be honest I imagine here Mike would have messed about with multiple beta’s of this product and I reckon you’d only get away with an extra 0.5mm or so at the most….still it’s an area they could tweak with in a follow up.
The Intake has a floating deck which appears to be press fit (at least I was unable to remove it); it has the same non-adjustable positive pin seen on the OBS series of tanks. Combined with the chamber I mentioned earlier and the base being press fit; it does make cleaning harder than some RTA’s on the market.
One of my favourite touches is the wicking channels being angled upward at 45 degrees running in line with the bubble glass outward extension. It lets you know exactly where you stand with wicking and more importantly no more juice bubbles sitting under the base or getting trapped against the glass, you’ve either wicked this right or you haven’t.
Finally just to end this section the tank breaks down into 5 parts (6 if using the 510 adaptor).
With top airflow RTA’s appearing round every corner and under every rock this year; it’s going to take something special at the mid-year mark for me to sit up and take note, in fact if I’m being completely honest I’m a little washed out at the thought of reviewing any more “samey” top airflow tanks, at least that is without keeping my finger firmly off the “yawn” re-run review button.
However Augvape were brave…praise both the vape and coil building gods; Mike gave us Snorkels baby! so In obligatory tradition Augvape kindly sent me the Intake RTA for the once over. As always I don’t like to make recommendations in my reviews, instead I’ll present you with my findings to help bolster your research should you be interested in the product.
Specification Overview & What’s in the box
- Visible Height: 45mm
- Diameter: 24mm at the base (27mm at widest part)
- Capacity: 4.2ml with bubble tank (3ml with straight glass)
- Thread length 4.19mm (gold plated positive pin)
- Construction: 304 Stainless Steel and Glass Construction
- Drip Tip (Stock shorty 810 – Tapered Bore 7.4mm > 11.3mm, Spare 810 – tapered bore 7.4mm > 13.5mm)
- Refill Port: 2 (kidney style 9 x 3.9mm)
- Airflow Slots: 2 (10 x 3mm)
- Chimney Bore: 5.9mm
- Air Tube Bore: 3.5mm (two tubes)
- Chamber width: 19mm
- Post distance for coil width: 6.5mm
- Deck length between posts: 6mm
- Chamber Height 9.4mm
- Airflow on Deck: Bottom airflow x 3 (each 2.7 x 2.1mm)
- Wicking hole Size: 4.4mm x 3.2mm
- Extras: Screws, Straight Glass, 510 Adaptor, O-rings, Tool, 2 spare screws, spare 810 drip tip
Available Colours: Black, Stainless, Blue, Gun Metal
Impressions, Build Quality & Assembly
Let’s start with the low profile stock drip tip, it’s unusual to say the least, it’ll be one of those you’ll either grow to like (unless you already happen to enjoy a tail pipe style of vaping) or like me it’ll remind you of one of those blow up pillow rings to relieve pile/coccyx pain. To be fair as with all of the releases Mikes involved with; he always makes sure there’s options included to cater for as many people as possible, so you have a taller, more normal 810 included with a slightly larger tapered bore (see my measurements). There’s also a 510 adaptor which is what I chose to use since the chimney bore is a 510 diameter anyway (at 5.9mm).
I appreciate why Mike went for the low profile tip because the whole top portion of the RTA is a little on the tall side, and running a tall drip tip would have enhanced that aspect further. To me it’s not the prettiest tank out there but it’s certainly functional. The top cap is a quarter twist bayonet style, and due to its height you have plenty to grab onto making refilling an absolute doddle; even for those who have weakness in their fingers. Not only that but the seal underneath has some decent flex to it; meaning it doesn’t squeeze juice out of the seams easily after fastening which I’ve seen on other top airflow atomisers.
The only area of critique around the top section is the O-ring holding the airflow ring in place. I think it would have been better to locate it at the top rather than bottom since juice has a tendency to get underneath it after removing/securing the top cap repeatedly.
Fit and finish is generally good throughout, as is the paintwork. On this matte black version you cannot see any of the gaudy branding we have become accustomed to from Mike in the past, even the engraved “Intake” writing on the chamber is difficult to see which I personally prefer. The only two areas of critique were the edges of my deck could have been sanded better during the final manufacturing stage; also the O-Ring around the base pops out a little too easily when cleaning so keep an eye you don’t lose it.
The tank comes with two types of glass, the 4.2ml bubble for those who like a little more capacity, and the 3ml straight for those who prefer the slender profile with their set ups. I managed to knock my mod over a few times since taking notes for this review and thankfully the bubble glass was thick enough to take it. This is an area to take into consideration when using slimmer mods though and I was probably lucky to get away with it, so note to self: use a band with the bubble as it extends out to 27mm diameter at its widest point, whereas the base is 24mm.
Some parts of the Intake design aren’t dissimilar to other top airflow released this year;
- The bayonet top cap idea I mentioned above has been about for a while and we’ve seen it on the likes of the Zeus and Themis already to name a couple, but it’s a great idea why the heck wouldn’t you use it!?
- The inside chamber has the flat ceiling which spins after you lock the airflow tubes into place. Like all of the others out there with this false ceiling; it’s the most difficult area of the atomiser to get behind and clean.
- It has a similar chimney diameter to all of the other single coiler top airflow RTA’s I’ve tried, meaning is actually suited to 510 drip tips well.
- It has similar sized kidney shaped refill ports accommodating all but the big twist top nozzle bottles.
- The base shape and its knurling reminds me little of the styling I’ve seen on others this year. In addition you can turn the tank upside down and unscrew the base to inspect the deck (if you’re careful).
- The Airflow Control Ring, is held in place in a similar way to others I’ve seen, again it makes sense so why not use it.
Really that’s where the similarities end though, considering how it looks on the outside they have managed to fit a lot inside that chamber housing, it’s a little like Dr. Who’s tardis: you get a decent build space, two snorkel tubes, 2 decent sized wicking wells and a wide bottom airflow all crammed into a 19mm diameter area, I’m pretty impressed. I fed back to Augvape (prior to this review) that I’d like to have seen those tubes sport slightly wider diameters just to increase the airflow range slightly, but to be honest I imagine here Mike would have messed about with multiple beta’s of this product and I reckon you’d only get away with an extra 0.5mm or so at the most….still it’s an area they could tweak with in a follow up.
The Intake has a floating deck which appears to be press fit (at least I was unable to remove it); it has the same non-adjustable positive pin seen on the OBS series of tanks. Combined with the chamber I mentioned earlier and the base being press fit; it does make cleaning harder than some RTA’s on the market.
One of my favourite touches is the wicking channels being angled upward at 45 degrees running in line with the bubble glass outward extension. It lets you know exactly where you stand with wicking and more importantly no more juice bubbles sitting under the base or getting trapped against the glass, you’ve either wicked this right or you haven’t.
Finally just to end this section the tank breaks down into 5 parts (6 if using the 510 adaptor).
