SMOK Baby Beast-coil fits

Discussion in 'Factory replacement heads and coils' started by georgemeadal, Jul 26, 2017.

  1. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    The SMOK baby Beast tank is very popular and has sort of become a "standard coil structure" in the vaping industry sort of like the Aspire Atlantis coil
    I have been working on this list and by no means is it perfect but I wanted to get it out there for all to see and help me improve on.This is my attempt to clarify what coils go in the baby beast tank. If anyone has better info or sees I have posted any wrong info please don't hesitate to add or correct me
    SMOK TFV8 Baby Turbo Engines Replacement Coils

    V8 Baby-T8 - .15 ohm octuple (4 hole)
    V8 Baby-Q2 .4 OR .6 ohm dual coil (single hole)
    V8 Baby-M2 .15 OR .25 OR .3 ohm dual coil (single hole)
    V8 Baby-X4 .15 ohm quadruple coil (two holes)-my favorite
    V8 Baby-T6 .2 ohm sextuple coil (three holes)
    V8 Baby RBA Head-DIY coil - ***Special RBA glass tube needed to use in Baby Beast and Big Baby Beast because the RBA coil is a few mm taller than standard coil!***

    TFV8 BABY BEAST NEW COILS

    [​IMG]

    Tanks that take these coils:


    CARRYS T4-R Resin Tank
    Eleaf ELLO Sub-Ohm Tank
    Eleaf Ello Mini
    Eleaf Mini XL Tank
    [​IMG] GeekVape Aero Mesh Sub-Ohm Tank

    Geek Vape Illusion Mini Tank takes Baby Beast coil AND WITH ADAPTER Atlantis/Triton coil
    iJoy EXO S Tank
    ijoy EXO X Tank

    **Joyetech ProCore Aries Tank**
    **ProCore coils fit the Big Baby Beast Tank but NOT the 22mm Baby Beast Tank**
    **The Baby Beast Coil will fit in the Joyetech ProCore Aries Tank**
    **see picture below, ProCore Coil is on the right and is wider than Baby Beast Coil**

    Joyetech ProCore Conquer

    Joyetech ProCore X Tank

    Sigelei Prism Tank - takes same SM2 / SM4 / SM6 coil as the Slydr-M and T3 Tank so....

    Sigelei Slydr-M Tank


    Sigelei T3 Tank - from ECIG CITY: The T3 Tank is yet another vibrantly bright addition to Fuchai's family showing off brilliant LEDs and utilizing the ever so familiar SM series of coils (also compatible with SMOK TFV8 Baby Beast Replacement Coils)

    SMOK TFV12 Baby Prince Tank


    SMOK TFV8 Baby Beast Tank

    SMOK TFV8 Big Baby Beast Tank

    SMOK Brit Beast Sub-Ohm Tank

    Squid Industries Peacemaker Tank

    Vapefly Fantasy Mini Tank-The M8 coil is also compatible with SMOK TFV8 baby tank and M2 using adapter compatible with Atlantis tanks.

    Vaptio Frogman

    Vapesoul VOne Tank

    Vaporesso Cascade Tank with the GT core adapter. - kellyND1, Today at 7:49 AM

    jennperry said:
    THE TFV8 Baby Beast Coils fit in the Vaporesso Cascade Tank with the NGR adapter. CONFIRMED!!!

    I've found that Only the T-6 & T-8 fit the Cascade tank. The others like the M, Q, or X don't. The series are straight cylinder shape and the others are a graduated cylinder...wider.at.bottom. My coils(the other 3) won't fit, too wide at bottom.
    Sent from my Pixel 2 XL using Tapatalk

    GT Cores are specially designed to fit into the NRG tank series, and now it is available for the all new Cascade Sub-Ohm Tank! It comes in traditional cotton and signature CCELL Ceramic in different resistances, from GT 2 all the way up to GT 8. Gear Up with GT Cores as you desire!

    Vaporesso NRG Tank ** WILL fit the ProCore Coil

    Wotofo Flow Sub Ohm Tank

    [​IMG]

    The Joyetech ProCore coil (on right) is wider than the SMOK Baby Beast coil (left) so it does NOT fit in the Baby Beast Tank (22mm)
    I am using it (Joyetech ProCore coil on right) no problem in my Big Baby Beast Tank

    Some aftermarket coils of note:[​IMG]
    Time to dust off your SMOK TFV8 Baby or Baby Beast Tank and bring it roaring back to life with Medusa's TFV8 Baby Staple Clapton Coils! Enjoy the warm and full vapor production of these impressive new coils. Available in 0.25 ohm for use at 25-80w, best at 55-65w.

    These coils are also compatible with the Wotofo Flow, Vaporesso NRG, Eleaf Ello, Eleaf Ello Mini, and Eleaf Mini XL tanks.

    Staple Clapton:


    • 0.25 Ω
    • Dual Core Staple Clapton Coil For use at 35-80W
    • We recommend using them at 55-65W for optimal performance.


    Attached Files:

    Last edited: Jun 25, 2018
    Just Frank, BPROSEK, Cormic and 3 others like this.
  2. richardrpsgt

    richardrpsgt Member For 3 Years

    Blog Posts:
    0
    Joined:
    Jul 27, 2014
    Messages:
    33
    Makes sense to me. Im running the x4 version in my Eleaf Ello tank now, so you might want to add that one.
    I would like to know how much taller the RBA is. Or actually, the difference between the standard glass and the RBA glass. With all the different tanks available im sure a suitable RBA glass can be found for each tank. That would also be a good list to have.

    Sent from my XT1650 using Tapatalk

    Just Frank likes this.
  3. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    So the Ello Tank will take the baby beast coil?!? Excellent! I'll add it to the list once you confirm.
    I'll also work on the glass tube size list. I have the ones for big baby beast and I used to have for the 22mm baby beast but I sold those off. I can do the research again by looking up purchases and compile it all here.
    Thanks again for the help!

  4. skt239

    skt239 VU Donator Platinum Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    Sep 16, 2015
    Messages:
    6,284
    The new wotofo (sp?) flow takes them

    georgemeadal likes this.
  5. richardrpsgt

    richardrpsgt Member For 3 Years

    Blog Posts:
    0
    Joined:
    Jul 27, 2014
    Messages:
    33
    Yup, they work! I saw in another forum they were using the procore aries coils in the Ello, so I finished the equation and bought a x4 coil to try. I was disappointed in the quality of the HW eleaf coils but the x4 has held up well.

    Sent from my XT1650 using Tapatalk

    georgemeadal likes this.
  6. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    Thanks!!

    skt239 likes this.
  7. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    Added info on GeekVape Illusion Mini and Vapefly Fantasy Mini Tanks

  8. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    Added info on the Asmodus Ohmie Tank

  9. anirban_k9

    anirban_k9 New Member

    Blog Posts:
    0
    Joined:
    Aug 30, 2017
    Messages:
    1
    Hi everyone I m from India and over here vaporresso NRG tank is totally new and seperate coils are not available still in india market . im very interested in buying vaporesso revenger kit but im stuck because of the non availabiltyof nrg tank coils . can anyone please confirm that if i buy nrg kit (vprso rvngr ) which coils (cross compatible) with NRG tank and it will be really grt of u all if u please specify the coils name .point- smok and eleaf coils are easily available in india .
    thank you in advance for the help...

    georgemeadal likes this.
  10. steever56

    steever56 New Member

    Blog Posts:
    0
    Joined:
    Aug 31, 2017
    Messages:
    1
    I tried for 20 minutes but could not get an X4 in the Ohmie tank. It appears the bottom thread design is larger on the Ohmie coils. Ihave now tried on 4 different Ohmie tanks with no luck

    Last edited: Aug 31, 2017
  11. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    Using https://www.elementvape.com/naked-100-x-asmodus-promo-bundle-ohmie-tank as my source. I'll update the post to reflect that Asmodus Ohmie needs at least one confirmation of success with a baby beast coil

  12. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    I have the Revenger Kit with the 5ml NRG tank and can confirm using Smok Baby Beast Q2, X4, and Joyetech ProCore C1,C2 coils in it.

  13. Mikey Gee

    Mikey Gee Member For 1 Year

    Blog Posts:
    0
    Joined:
    Apr 25, 2017
    Messages:
    20
    Great list since no one locally carries Vaporesso NRG coils! Blew through 5 coils quickly and had to go back to my Geekvape and Vaporesso RTAs. Does anyone have any input about how long the coils are lasting? Everyone I know that uses the Smok coils say they drink the juice and do not last long at all maybe 2-3 days! Wondering if any other manufacture has a longer lasting coil.
    Have you found out any additional information on the RBAs that will fit in the NRG tanks? I've been more an more using my RTAs and enjoy the flavor much more than the pre-built coils. From my research it seems to be the Baby Beast RTA is about 3mm taller than the coils so to use that I would have to get a glass that is 3mm taller than current. That may be a question for another post...

    georgemeadal likes this.
  14. v_lestat

    v_lestat New Member

    Blog Posts:
    0
    Joined:
    Nov 23, 2014
    Messages:
    6
    baby beast coils do NOT fit in the Ohmie tank, the threads on the base aren't right. chimney threads in and that's all.

  15. Nnutthowzenick

    Nnutthowzenick New Member

    Blog Posts:
    0
    Joined:
    Nov 9, 2016
    Messages:
    2
    So I've never really like the big baby beast because I vape at 120 plus watts I like the 12 but for some. Mods it's just stupid big is there a coil I could use in a big baby thay has good flavor and vapor and vape 120 plus watts

  16. Nnutthowzenick

    Nnutthowzenick New Member

    Blog Posts:
    0
    Joined:
    Nov 9, 2016
    Messages:
    2
    What coil can I use in the big baby and vape at 120plus watts and get good flavor

  17. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    I am not sure ( I rarely vape over 50 watts) but here is some info from SMOK about the variety of coils and recommended wattage.
    [​IMG]
    Some info from the Ijoy for the exo tank coils.
    [​IMG]

    Some info from the Geek Vape about the Illusion Mini (top coil only).
    [​IMG]

    Joyetech info...
    [​IMG]

    ...
    From the Sigelei website: for Slydr-M Tank / Prism Tank / T-3 Tank
    sm coils.jpg

    Last edited: Nov 14, 2017
  18. WillKillin

    WillKillin New Member

    Blog Posts:
    0
    Joined:
    Oct 1, 2017
    Messages:
    1
    So I just got back from the vape store and I've been trying to do some research after he told me I could get Joyetech's that fit my Big Baby Beast tank because they last longer. This is literally the only page on the entirety of the web talking about it. So I was just curious as to which one's fit the Big Baby Beast? I love the octuplet coils, is their a Joytech equivalent of that also? Any help would be appreciated :)

    georgemeadal likes this.
  19. Nick639

    Nick639 New Member

    Blog Posts:
    0
    Joined:
    Oct 1, 2017
    Messages:
    4

    Did you get an answer/solution on this?? I’m also interested in making my NRG rebuildable :)

    georgemeadal likes this.
  20. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    In the post above I show which Joyetech coils are available. The V8 Baby T-8 coils have 4 holes (8 coils) which are comparable I assume to the Joyetech Pro C4 coil, although I have never tried those.

  21. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    I have not tried any of the RBA coils in the NRG tank BUT I did read somewhere that the iJoy EXO-X and EXO-S RBA is the same height as the regular coil so maybe try purchasing one of those and give us your results.

  22. Nick639

    Nick639 New Member

    Blog Posts:
    0
    Joined:
    Oct 1, 2017
    Messages:
    4
    I’ll see if i can get my hands on it. I also have a veco spare glass which is indeed a little longer than the nrg.. maybe the rba coils may fit now... until then if anyone else got a rba coil in an nrg please post


    Sent from my iPhone using Tapatalk

    georgemeadal likes this.
  23. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    From a discussion at Fasttech: https://www.fasttech.com/forums/6897800/t/2377853/should-work-in-tfv8-baby/2

    It won't fit in the Baby Beast, Big Baby Beast, Limitless XL rta or Exo XL rtas. Below are the measurements for all 4 rba's.The Baby Beast and Big Baby Beast rba's are 21.4mm high and 16mm wide.The Limitless XL rba's are 19.8mm high and wide.The Exo XL rba is 20mm all around.This rba is 28mm high and 22mm wide.



    This is super wrong. The normal baby coils work in this tank and therefore it must work vice versa.

    If this does not come with its own glass piece it must mean it's the same height as the stock exo coils. The exo prebuilt coils with their height and width MUST work in the baby beast based on my previous point. Logic would have it that the xs1 RBA does as well.

    The width is going to be the same for both of these (I am not talking to the limitless tanks at all as I'm not sure how they made their way into this thread and I have no knowledge of them) There is no way the xs1 RBA is 22mm wide as that is the width of the tank itself.

    The height of the baby beast RBA in comparison to this one does not matter. What matters is the xs1 rba's height in comparison to prebuilt coils for the exo and babys.

  24. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    Maybe...
    https://www.ijoyusa.com/collections/coils/products/copy-of-exo-xs-c4-coil although the picture isn't correct...WTF

  25. Just Frank

    Just Frank Gold Contributor Member For 1 Year

    Blog Posts:
    0
    Joined:
    Mar 17, 2017
    Messages:
    2,516
    How good are the SS coils for the ello tank? I like the smok q2 coils but prefer stainless usually.

  26. Dave Bryson

    Dave Bryson New Member

    Blog Posts:
    0
    Joined:
    Jan 21, 2017
    Messages:
    5
    which brand of coils do you prefer for the nrg tank??

    georgemeadal likes this.
  27. Nick639

    Nick639 New Member

    Blog Posts:
    0
    Joined:
    Oct 1, 2017
    Messages:
    4
    24.4mm glass will work with baby rba coil on the nrg tank.


    Sent from my iPhone using Tapatalk

    georgemeadal likes this.
  28. SkoldVape

    SkoldVape Gold Contributor Member For 1 Year

    Blog Posts:
    0
    Joined:
    Apr 10, 2017
    Messages:
    2,590
    Thanks for the list. I have used the baby beast for a year and didn't know there was a T6 coil. I'll be ordering some to see how they are but as it stands I only like the X4. Don't care for the M2 coils

  29. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    SkoldVape likes this.
  30. SkoldVape

    SkoldVape Gold Contributor Member For 1 Year

    Blog Posts:
    0
    Joined:
    Apr 10, 2017
    Messages:
    2,590
    georgemeadal likes this.
  31. chinqz

    chinqz New Member

    Blog Posts:
    0
    Joined:
    Nov 9, 2017
    Messages:
    1
    Where did you get the 24.4mm glass? i cant seem to find it anywhere. i really would like an RBA for the NRG tank as the GT coils are not that great they last 2-3 days at most for me. or does anybody else know any other RBA besides the TFV8 baby RBA that would work with the NRG tank?

  32. Nick639

    Nick639 New Member

    Blog Posts:
    0
    Joined:
    Oct 1, 2017
    Messages:
    4

    24.4mm glass i have was cut from a cloudbeast tank




    Sent from my iPhone using Tapatalk

  33. MichelleTearsofCrimson

    MichelleTearsofCrimson Member For 2 Years

    Blog Posts:
    0
    Joined:
    Oct 5, 2015
    Messages:
    126
    What about replacement coils for M2 The Baby Beast "Brother" I'm burning out in 3 days

    Just Frank likes this.
  34. Just Frank

    Just Frank Gold Contributor Member For 1 Year

    Blog Posts:
    0
    Joined:
    Mar 17, 2017
    Messages:
    2,516
    I thought the xbaby coils were shit. I never got any more and shelved the tank. Piece of junk.

    I had to edit this post. The T6 coils for the Xbaby were my saviour. I won't use a single cylinder coil in this tank.

    Last edited: Jun 26, 2018
  35. KP78

    KP78 New Member

    Blog Posts:
    0
    Joined:
    Dec 19, 2017
    Messages:
    8
    I ordered Smok V8 baby rba for my Ello mini tank. Noticed it is taller, and the glass that came with it will not fit to Ello mini (too high, leaving gap between rba and chimney).
    Well, I had one black replacement glass for Smok micro TFV4 (that didn't fit for micro tfv4 plus tank), so tried that on Ello mini.
    Yes, it fits!
    Eleaf Ello mini (2ml) + Smok V8 baby rba + Smok micro TFV4 plus glass.

    Just Frank and georgemeadal like this.
  36. KP78

    KP78 New Member

    Blog Posts:
    0
    Joined:
    Dec 19, 2017
    Messages:
    8
    Only one thing: V8 baby rba on Ello mini may not have space for juice flowing to coils, there is barely 0.01mm space between rba and gasket.

  37. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    So I have the ello tank on the way. There is a ello , ello t, and ello s. From what I can tell, not that much difference. Drip tip, filling method. But all take HW coils. 1,2,3,4. And all the other coils listed in op will work in ello tank from what I've read.
    Now the RBA topic. The most impt to me.
    Smok Baby rba won't work. Bc it comes with new glass to make Smok tank taller. So out for the ello. Guess I should just get the eleaf ERL rba coil. Same company has to fit....?
    What about joyetech rba, vaporesso rba.. And all the other companies...

  38. KP78

    KP78 New Member

    Blog Posts:
    0
    Joined:
    Dec 19, 2017
    Messages:
    8
    I was considering ERL, but as I have Aspire Triton RTA system which I use (also works with Ello and Ello mini EDIT: no, works with iJust S) and thought ERL too similar, didn't order that. Reason for V8 baby rba was similarity to micro r2 that I have been using with micro TFV4 plus tank and find it lot easier to setup than Triton RTA.
    Now I have ordered new glass I hope will fit with Ello tank (4ml) and V8 baby rba. Ello glass is again too short, so need few mm taller for it.

    Edit: mixed up in my mind ERL with ECR that I was thinking for iJust S tank, not for Ello!
    So ERL would be better for Ello than V8 baby rba because it should fit.

    Last edited: Dec 23, 2017
    Redscaddy22 likes this.
  39. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    Erl rba is velocity post. I should be good with that. Pretty simple. Anybody have thoughts opinion on it?

  40. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    Bad news... I got the ello t tank in today to go with the invoke mod. Also purchased and shipped with the ello t tank was the eleaf erl rba. I thought after the 2 coils that come with the tank I would use the rba.. the eleaf erl rba is wayy to big to fit in the ello t tank. Sucks. I thought it was going to be compatible. So now need another rba that will fit ? I can show pics if ya want.

  41. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    The only one I have (because it's the only one I have been able to actually get) is the SMOK V8 BABY RBA KIT (with the tall glass).

  42. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    So that fits in the ello t tank? With the Smok glass, or the small ello glass, or the tall ello glass with the extender piece?

  43. georgemeadal

    georgemeadal Gold Contributor Member For 3 Years

    Blog Posts:
    0
    Joined:
    Apr 8, 2015
    Messages:
    1,943
    I'm sorry but I do not know. I do know that the height difference between the normal(20mm) glass and the RBA (22.3)glass is 2.3mm (taller).
    Find a replacement tank that is the same diameter as the ELLO and 2.3mm taller and you should be GTG...


    Sent from my VS990 using Tapatalk

    Redscaddy22 likes this.
  44. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    Thanks for info! I'm just gonna order it. Only 10 bucks.

  45. KP78

    KP78 New Member

    Blog Posts:
    0
    Joined:
    Dec 19, 2017
    Messages:
    8
    I now have v8 baby rba in my regular ello (the basic one 4ml tank without added letters), with v8 big baby tank (fasttech sku 7149100) and it works, but base gasket needed modification with knife. Gasket is too tight, it won't let juice flow without knife.

    Redscaddy22 likes this.
  46. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    Cut away some? From the inner side?

  47. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    How is the baby rba? Drinking juice?

  48. KP78

    KP78 New Member

    Blog Posts:
    0
    Joined:
    Dec 19, 2017
    Messages:
    8
    Yes, cut some from inner side to get juice flowing as it should and no dry hits.
    Baby rba is not drinking too much juice in my use. But of course if you put .3 coils in and lots of power, it will drink a lot. With coils that come with it and low power it feels very good.

  49. Redscaddy22

    Redscaddy22 Silver Contributor Member For 2 Years

    Blog Posts:
    0
    Joined:
    May 8, 2016
    Messages:
    815
    Nice! Few more questions.. Will the baby rba glass work on ello. Or you have to get baby rba , big baby glass, and ello?

  50. KP78

    KP78 New Member

    Blog Posts:
    0
    Joined:
    Dec 19, 2017
    Messages:
    8
    For my ello tank baby rba glass was wrong size. Not sure about those editions with added letters (ello s and so).
    You need to try, I measured ello glass to be about 3mm too short so I hunted fasttech.com for different glasses and found big baby glass near correct so ordered it and it fits 99%. Just put baby rba first into chimney, then put base. Otherwise chimney *may* get some gap.


Share This Page

Close This Message
