I Have watted all over the place. But after a while I settled into 3 main categories that are my preferred range.
**Forewords - My favorite builds are for intermediate and up builders. I will add novice builder alternatives to each build. My preferred gauges, for my favorite vapes, are almost always 28g or 30g frames, .3x.1 ribbon, and 38g or 40g fuse. The alloys I choose are usually Ni80 Frames and KA1 Ribbon. Since these babies can be a LOT of metal to heat, the NiChrome helps bring down the ramp time and the Kanthal helps keep the resistance in a manageable range**
***Warning - use HIGH drain batteries for these builds!! In a regulated mod you can only pull approx 55-57w, per 20a battery, safely. For single battery unregulated, you will need at least 25a batteries***
Single Coil 60-70w:
The Coils-
When I'm in the mood for a "cooler" (cooler being relative to blowing your face off
) vape this is where I like most of my single coils. As an artistic builder most of my single coils have a lot of wire in them. They typically have over 1.5mm wide leads (and often over 2mm) and ohm in between .12-.18 with 2.5-3.5 wraps on a 4mm ID. I am partial to Staple Staggered Fused Claptons (SSFC-Staggered frames around a stack of ribbon and fused between the staggers) in this category. In my opinion, and at the wattages I like to vape them, these coils tend to be a smidge cooler than Framed staples, have better flavor due to more places for the liquid to pool, have less pop and sizzle since the liquid doesn't become "trapped" between the fuse and the cores, and have incredible wicking properties giving you longer life on your cotton. .
Here is a slight variation on a basic SSFC-
View attachment 123168
Novice Alternative - Framed Staple
View attachment 123170
The Atomizers -
I am on a budget so I don't have an array of RDA's to choose from. For the most part most of my single coils go into the VandyVape Pulse24 since it's the only one I have that will hold the monsters. If I'm not building to intricate, and can keep the ohms down far enough, I will do a 3.5mm ID and throw them in the KTX. I plan on Picking up the Wotofo/MikeVapes Recurve, or the Asmodus C4, in the near future for a dedicated single coil RDA.
The Mods -
For this range I typically put them on any regulated mod. But Mostly I enjoy squonking them on my VandyVape Pulse80w.
Dual Coil 100-110 watts:
This is where I spend most of my time.
The coils -
I have 2 favorite builds for this range, both being dual coil.
First is an Interlocking Fralien (a framed staple fused with a paralleled decore). I have not yet pinpointed what exactly makes this such a great vape for me. So, I honestly can't tell you the "why" lol. My assumption is that it is similar to a SSFC, with the space between the fuse.
30/6ply/40, 3.5mm ID, 4.5 wrap dual coil, .16 ohm dual coil at 100-105w (approx 4v)
View attachment 123169
Novice alternative - Fralien (Framed Staple with an alien fuse)
This is a rather large build for dual coil. It's just a pic for reference
View attachment 123171
Next is a Half staggered Half framed staple. Basically this is an SSFC but missing 1 frame. This build gives you all the benefits of an SSFC but allows you more leeway with resistance and gives you the ability to add more ribbon to ramp up the heat. The pic is what is known as a half pitchfork and is much more in depth than just doing a half stag. But I honestly find it to be a bit more flavorful than just doing a half stag.
Half Pitchfork - 2x 4 ply .3/28/40, 4.5 wraps on a 3.5mm ID, .14 ohms at 110w (just under 4v)
****Warning - This pulls 28 amps on an unregulated mod****
View attachment 123172
Novice Alternative - 28/38/.3r Half Framed Staple
Don't have a pic for this but it's a standard framed staple but without 1 of the round wire frames.
The Atomizers -
Depending on your vape style, this high wattage is a balancing act of getting enough air but not being so open that you still get good flavor. For me I like a slightly restricted airflow. I find the honey comb style to give me that nice little restriction while also allowing for enough direct air to keep the flavor in a good place.
The Mods -
Depending on your batteries you can either do a regulated or parallel unregulated. I personally like to vape these in regulated. I find the voltage sag on unreg to pull the wattage down to much for me.
Dual Coil Unregulated Series vaping 140-150w:
This will blow your face off!!! I thoroughly enjoy series vaping. But be warned it is a super hot and heavy vape.
The Coils -
This is a balancing act between pulling out flavor while also keeping your resistance in a place that wont melt your mod. My first choice is a 3 core 32/42 alien, 6.5 wraps on a 3.5mm ID, .47 ohm. I like the fine wire core, and larger ID, because I find less wraps gives me a more satisfying vape
View attachment 123176
Novice Alternative - And my second "go to" build for unregulated series vaping is some variation on a twisted clapton. This is a twisted 3 core (2 of them claptoned) 30/42, dual coil, 8.5 wraps on a 3.5mm ID, .47 ohms
View attachment 123177
Novice alternative - Single Wire Clapton
26g core with 38 and 40g parallel clapton (38g only clap for novices), 9.5 wraps (8.5 would be better), 3.5mm ID, .58 ohm (.5 with 8.5 wraps)
View attachment 123179
The Atomizer -
My personal favorite, from my collection, for series vaping is the Voopoo Rune. It is slightly restricted airflow. But when installed correctly the direct bottom airflow is enough to keep the coils from burning your cotton.
The Mod -
The only series mod I have is the Noisy Cricket-II
Dual Coil ridiculousness 200 watts
And last but not lease something "dangerous" ... You MUST have super high drain batteries!!!!! You will be pulling at least 25 amps on an unregulated series mod. And this will be a ridiculous vape if your not used to it. I build this on occasion and I always find it satisfying, if not sometimes a little overwhelming.
2 core 28/38 Alien (a fused clapton works as well), 7.5 wraps on a 3.5mm ID, .35 ohms, ~200w
Don't have a pic available but it looks just like every other alien
